Mismatched SMD package size is a recipe for disaster. Forcing a small package onto a larger pad causes misalignment. During reflow, solder surface tension pulls the pins randomly, leading to bridging. #JLCPCB #SMD #Transistor #Soldering #PCBDesign #ElectronicsEngineering
2
JLCPCB
@JLCPCB
Sep 4
Why is this capacitor placed so close to the IC? 👀 It could sit centimeters away, but it’s right next to the power pin. Coincidence? Nope. What’s being minimized? A. Voltage drop B. Loop area / parasitic inductance C. PCB space D. Cost Your answer? 👇 #JLCPCB #PCBLayout
4
JLCPCB
@JLCPCB
Sep 3
POV: You forgot OCP. 💥 Short circuit = melted diode art. 🎨 Add fuses before the fireworks. 😅 Who let the Magic Smoke out? 👇 #EngineeringLife #Electronics #JLCPCB
JLCPCB
@JLCPCB
Sep 2
What if a PCB were a city? 🌃 Traces = roads Components = buildings Vias = intersections Signals = traffic ⚡ No traffic jams. Just pure engineering logic. City, map, or maze? What do you see? 👇 #PCBDesign #HardwareEngineering #JLCPCB
