REhab runner

A game designed to entertain and engage patients during their physical rehabilitation.

Comment

RehabRunner

Inspiration

Making rehabilitation accessible and engaging across age groups.​ Producing a cost-effective solution for people with physical injuries.​ Bringing the solution straight to the user.​ Providing a social distancing aid during the pandemic.

What it does

Controls a character avatar based on the patient's gestures to dodge objects on screen in 3D game environment.

How we built it

Built 3 main game components as follows- Game - Unity, C# Scripting Pose Estimation - OpenPose + Machine Learning + Custom Algorithm Dashboard - React JS, Flask, MongoDB

Challenges we ran into

Socket and webcam incompatibility, creation of new and optimal algorithms.

Accomplishments that we're proud of

Implementing custom action detection using point-based pose estimation and calculations, fully working dynamic 3D game and online dashboard.

What we learned

How to communicate between Python scripts for computer vision/machine learning and a Unity-based game app, how patients undergo rehabilitation and how to incorporate this medical information with an engaging game. References: https://www.researchgate.net/publication/265307870_Movement_Analysis_of_Rehabilitation_Exercises_Distance_Metrics_for_Measuring_Patient_Progress https://www.ncbi.nlm.nih.gov/pmc/articles/PMC5526359/

What's next for REhab runner

Increase speed and accuracy of point-based pose estimation, online deployments, look into kinect implementation.

RehabRunner is a hack designed to help people who are suffering from physical injuries and require rehabillitation in current times.

  1. RehabRunner enables people to save a lot of money required in physical rehabillitation by providing computer vision technologies to tackle this problem.
  2. It saves time by reducing the time people take to travel to the hospital.
  3. Studies show that during COVID times most of the spaces inside major hospital's orthopaedic units have been repurposed to house people suffering from COVID symptoms. RehabRunner helps with social distancing and takes care of the problem of space constraints inside hospitals.
  4. RehabRunner helps target children by providing a gamified way to rehabillitate children.

Components of Hack

  1. Game
  2. Pose estimation
  3. Exercise detection
  4. Dashboard

1. Game

Use

The Game has been made in order to provide a fun and interactive method to enable people to undergo what is usually a very painful and long process.

Tech involved

  1. The Game is made using unity, the game was custom built during the hackathon and is a pretty fun game.
  2. The game communicates with a python backend to do most of the image processing, this connection is made using a TCP connection. Real time results are computed and sent back with minimal lag.
  3. The player is then able to control his in game character to play the game.

2. Pose Estimation

Use

We use pose estimation in order to detect the movement of key joints of a person, these results are useful in calculating whether a person succesfully exercises.

Tech involved

  1. The pose estimation model uses pretrained COCO model and is built in python
  2. The model receives the information data from the game frontend using a TCP socket connection
  3. The model then runs the predictions of each frame in a queue sending in the results, the threading enables us to get results with a delay of around 1.2 ms

3. Exercise Detection

Use

We use this part to detect whether the person is performing a correct action given a sequence of points from the pose estimation

Tech involved

  1. Finding datasets for this very niche problem was very hard, we found a lot of videos from the internet of some basic exercises and recorded some videos as well.
  2. We use a delta based approximation algorithm to find whether a person correctly completes an exercise, we measure how well he does it using a threshold.

4. Dashboard

Use

  1. The dashboard is a website we built inorder for users to measure their physical therapy progress over time based on how well they've played our game.
  2. The dashboard shows calendar progress of a user
  3. The dashboard shows his average score he gets in his exercise
  4. The dashboard also show the time to the next doctor's consultation

Tech involved

  1. We use a mongodb server, react frontend and flask backend to run this dashboard.

Setup guide

Pose estimation and exercise Detection

Run the following commands on a linux based system

cd Pose_Estimation/
sh ./get_model.sh
virtualenv env
source env/bin/activate
pip install -r requirements.txt

To run the python program on a loop

python run_pose.py

Unity

Copy paste all the folder except Pose_Estimation, Dashboard to the unity folder and run the unity game. Upon clicking run the game is built

Dashboard

  1. backend To install the backend for the dashboard run the following commands on a linux terminal
cd Dashboard/backend/
virtualenv env
source env/bin/activate
pip install -r requirements.txt

To run the backend

python main.py
  1. frontend

To setup the frontend

cd Dashboard/frontend/
npm install

To run the frontend

python main.py
