RegOT is a collection of state-of-the-art solvers for regularized optimal transport (OT) problems, implemented in efficient C++ code. This repository is the Python interface to RegOT.

RegOT mainly solves two types of regularized OT problems: the entropic-regularized OT (EROT) and the quadratically regularized OT (QROT).

EROT, also known as the Sinkhorn-type OT, considers the following optimization problem:

where $a\in\mathbb{R}^n$ and $b\in\mathbb{R}^m$ are two given probability vectors with $a_i>0$, $b_j>0$, $\sum_{i=1}^n a_i=\sum_{j=1}^m b_j=1$, and $M\in\mathbb{R}^{n\times m}$ is a given cost matrix. The function $h(T)=\sum_{i=1}^{n}\sum_{j=1}^{m}T_{ij}(1-\log T_{ij})$ is the entropy term, and $\eta>0$ is a regularization parameter.

QROT, also known as the Euclidean-regularized OT, is concerned with the problem

Currently RegOT contains the following solvers for EROT (methods marked with 🌟 are developed by our group!):

• sinkhorn_bcd: the block coordinate descent (BCD) algorithm, equivalent to the well-known Sinkhorn algorithm.
• sinkhorn_apdagd: the adaptive primal-dual accelerate gradient descent (APDAGD) algorithm (link to paper).
• sinkhorn_lbfgs_dual: the L-BFGS algorithm applied to the dual problem of EROT.
• sinkhorn_newton: Newton's method applied to the dual problem of EROT.
• 🌟sinkhorn_sparse_newton: Newton-type method using sparsified Hessian matrix, as described in our SPLR paper.
• 🌟sinkhorn_ssns: the safe and sparse Newton method for Sinkhorn-type OT (SSNS, link to paper).
• 🌟sinkhorn_splr: the sparse-plus-low-rank quasi-Newton method for the dual problem of EROT (SPLR, link to paper).

The following solvers are available for the QROT problem:

• qrot_bcd: the BCD algorithm.
• qrot_gd: the line search gradient descent algorithm applied to the dual problem of QROT.
• qrot_apdagd: the APDAGD algorithm (link to paper).
• qrot_pdaam: the primal-dual accelerated alternating minimization (PDAAM) algorithm (link to paper).
• qrot_lbfgs_dual: the L-BFGS algorithm applied to the dual problem of QROT.
• qrot_lbfgs_semi_dual: the L-BFGS algorithm applied to the semi-dual problem of QROT (link to paper).
• qrot_assn: the adaptive semi-smooth Newton (ASSN) method applied to the dual problem of QROT (link to paper).
• qrot_grssn: the globalized and regularized semi-smooth Newton (GRSSN) method applied to the dual problem of QROT (link to paper).

You can simply install RegOT using the pip command:

pip install regot

A C++ compiler is needed to build RegOT from source. Enter the source directory and run

pip install . -r requirements.txt

The code below shows a minimal example computing EROT given $a$, $b$, $M$, and $\eta$.

import numpy as np
from scipy.stats import expon, norm
import regot
import matplotlib.pyplot as plt

# OT between two discretized distributions
# One is exponential, the other is mixture normal
def example(n=100, m=80):
    x1 = np.linspace(0.0, 5.0, num=n)
    x2 = np.linspace(0.0, 5.0, num=m)
    distr1 = expon(scale=1.0)
    distr2 = norm(loc=1.0, scale=0.2)
    distr3 = norm(loc=3.0, scale=0.5)
    a = distr1.pdf(x1)
    a = a / np.sum(a)
    b = 0.2 * distr2.pdf(x2) + 0.8 * distr3.pdf(x2)
    b = b / np.sum(b)
    M = np.square(x1.reshape(n, 1) - x2.reshape(1, m))
    return M, a, b

# Source and target distribution vectors `a` and `b`
# Cost matrix `M`
# Regularization parameter `reg`
np.random.seed(123)
M, a, b = example(n=100, m=80)
reg = 0.1

# Algorithm: block coordinate descent (the Sinkhorn algorithm)
res1 = regot.sinkhorn_bcd(
    M, a, b, reg, tol=1e-6, max_iter=1000, verbose=1)

# Algorithm: SSNS
reg = 0.01
res2 = regot.sinkhorn_ssns(
    M, a, b, reg, tol=1e-6, max_iter=1000, verbose=0)

We can retrieve the computed transport plans and visualize them:

def vis_plan(T, title=""):
    fig = plt.figure(figsize=(8, 8))
    plt.imshow(T, interpolation="nearest")
    plt.title(title, fontsize=20)
    plt.show()

vis_plan(res1.plan, title="reg=0.1")
vis_plan(res2.plan, title="reg=0.01")

🌟 Fun fact: The logo sticker of RegOT also uses the package itself to compute the transport pattern between point clouds. You can use this code to reproduce the image.

Please consider to cite our work if you find our algorithms or software useful in your research and applications.

@inproceedings{tang2024safe,
  title={Safe and sparse Newton method for entropic-regularized optimal transport},
  author={Tang, Zihao and Qiu, Yixuan},
  booktitle={Advances in Neural Information Processing Systems},
  volume={37},
  pages={129914--129943},
  year={2024}
}

@inproceedings{wang2025sparse,
  title={The Sparse-Plus-Low-Rank quasi-Newton method for entropic-regularized optimal transport},
  author={Wang, Chenrui and Qiu, Yixuan},
  booktitle={Forty-second International Conference on Machine Learning},
  year={2025}
}
