Circular Queue in Java

Circular Queue in Java

Circular Queue in Java is an efficient type of queue that overcomes the space wastage limitation of a normal (linear) queue. In a normal array based queue, once the rear reaches the end, you cannot insert more elements even if there’s vacant space at the front. A circular queue “wraps around” to reuse empty positions in the array, forming a logical circle.

This makes both enqueue (insertion) and dequeue (removal) efficient and ideal for fixed size buffers such as process schedulers, traffic systems, and streaming buffers (ring buffers).

circular queue in java programming

What is a Circular Queue?

Queue is a linear data structure which follows First In First Out (FIFO) principle. But there are some limitations in normal queue. If the rear reaches to the end of the queue then there might be possibility that some vacant spaces are left in the beginning which cannot be utilized.

So , to overcome such limitations , the concept of the circular queue was introduced.

The following are the operations that can be performed on a circular queue:

  1. Front : It is used to get the front item from the queue.
  2. Rear : It is used to get the last element from the queue.
  3. enQueue(value): This function is used to insert the new value in the queue . The new element is always inserted at the rear end.
  4. deQueue() : This function deletes an element from the queue. The deletion in queue always takes place from the front end.
Operation in Circular Queue

How Circular Queue works?

  1. Use a fixed size array.
  2. Maintain:
    • front pointer — index of first element
    • rear pointer — index of last element
    • Optional size to track count
  3. For wrap around movement:
nextIndex = (currentIndex + 1) % capacity

This ensures that when you reach the end, you wrap back to the beginning.

Algorithm for Implementation in Circular Queue in Java

For – isFull:

  1. If (front == 0 && rear == capacity – 1)
    • return true
  2. Else if (front == (rear + 1) % capacity)
    • return true
  3. Else
    • return false

For – isEmpty:

  1. If front == -1
    • return true
  2. Else
    • return false

For – enqueue (Insertion)

  1. If isFull()
    • Queue is full
  2. Else
    1. If front == -1
      • front = 0
    2. rear = (rear + 1) % capacity
    3. queue[rear] = value

For – dequeue (Deletion)

  1. If isEmpty()
    • Queue is empty
    • return -1
  2. value = queue[front]
  3. If front == rear
    • // only one element
    • front = rear = -1
  4. Else:
    • front = (front + 1) % capacity
  5. Return Value

Learn DSA

Prime Course Trailer

Related Banners

Get PrepInsta Prime & get Access to all 200+ courses offered by PrepInsta in One Subscription

Java Code for Implementation in Circular Queue in Java

Run
import java.util.Scanner;

public class CircularQueue {

    private int front, rear, capacity;
    private int[] queue;

    public CircularQueue(int size) {
        capacity = size;
        queue = new int[capacity];
        front = -1;
        rear = -1;
    }

    // Check if queue is full
    public boolean isFull() {
        return (front == 0 && rear == capacity - 1) ||
               (front == (rear + 1) % capacity);
    }

    // Check if queue is empty
    public boolean isEmpty() {
        return front == -1;
    }

    // Enqueue operation
    public void enqueue(int value) {

        if (isFull()) {
            System.out.println("Queue is full. Cannot insert " + value);
            return;
        }

        if (front == -1) {   // first element
            front = 0;
        }

        rear = (rear + 1) % capacity;
        queue[rear] = value;
        System.out.println(value + " inserted");
    }

    // Dequeue operation
    public int dequeue() {

        if (isEmpty()) {
            System.out.println("Queue is empty (Underflow)");
            return -1;
        }

        int value = queue[front];

        // If this was the last element
        if (front == rear) {
            front = -1;
            rear = -1;
        } else {
            front = (front + 1) % capacity;
        }

        return value;
    }

    // View front element
    public int peek() {
        if (isEmpty()) {
            System.out.println("Queue is empty");
            return -1;
        }
        return queue[front];
    }

    // Display queue
    public void display() {

        if (isEmpty()) {
            System.out.println("Queue is empty");
            return;
        }

        System.out.print("CircularQueue: ");

        int i = front;
        while (true) {
            System.out.print(queue[i] + " ");
            if (i == rear) break;
            i = (i + 1) % capacity;
        }
        System.out.println();
    }

    // Main to test CircularQueue
    public static void main(String[] args) {

        Scanner sc = new Scanner(System.in);

        System.out.print("Enter queue capacity: ");
        int cap = sc.nextInt();

        CircularQueue cq = new CircularQueue(cap);

        System.out.println("Choose operations:");
        System.out.println("1 = enqueue");
        System.out.println("2 = dequeue");
        System.out.println("3 = peek");
        System.out.println("4 = display");
        System.out.println("5 = exit");

        while (true) {
            System.out.print("\nEnter choice: ");
            int choice = sc.nextInt();

            switch (choice) {

                case 1:
                    System.out.print("Enter value: ");
                    int val = sc.nextInt();
                    cq.enqueue(val);
                    break;

                case 2:
                    int removed = cq.dequeue();
                    if (removed != -1) {
                        System.out.println("Removed: " + removed);
                    }
                    break;

                case 3:
                    System.out.println("Front: " + cq.peek());
                    break;

                case 4:
                    cq.display();
                    break;

                case 5:
                    System.out.println("Program terminated.");
                    sc.close();
                    return;

                default:
                    System.out.println("Invalid choice");
            }
        }
    }
}

Input:

Enter queue capacity: 3
1 10
1 20
1 30
1 40
4
2
2
1 50
4

Output:

10 inserted
20 inserted
30 inserted
Queue is full. Cannot insert 40
CircularQueue: 10 20 30
Removed: 10
Removed: 20
50 inserted
CircularQueue: 30 50

Comparison with Linear Queue:

Feature Linear Queue Circular Queue
Space Usage Wastes space after deletions Efficient reuse of space
Overflow Condition Rear reaches end of array Only when queue is truly full
Enqueue/Dequeue Cost O(1) O(1)
Ease of Implementation Simple Moderate

Frequently Asked Questions

Answer:

A circular queue is a queue where the rear moves to the front after reaching the end, allowing efficient reuse of space.

Answer:

Circular queue avoids space wastage after deletions by wrapping pointers back to the start.

Answer:

Both enqueue and dequeue operations run in O(1) time.

Answer:

A circular queue is full when (rear + 1) % capacity == front.

Answer:

Does Java provide a built in Circular Queue?
