The Ultimate RF Transceiver for Software Defined Radio (SDR) Applications

Iris Chip


The Ultimate RF Transceiver for SDR applications

Sequans Iris is a state-of-the-art family of RF Integrated Transceivers designed for Software Defined Radio (SDR) applications. Engineered for mission-critical use in defense, aerospace, drones, V2X, routers, and other advanced 5G systems, Iris redefines the benchmarks for RF performance, flexibility, and reliability.

The Iris product line stems from Sequans’ strategic acquisition of ACP in early 2025. ACP, a recognized pioneer in RF semiconductor innovation, has shipped millions of transceivers powering cutting-edge applications such as 5G small cells, drones, and V2X systems.

Iris SQN9506

20 Rx, 4 Tx Wideband RF Transceiver


The Sequans Iris SQN9506 is a cutting-edge integrated wideband RF transceiver designed for agile SDR applications. Operating across a frequency range from 220 MHz to 7.125 GHz, it offers an impressive instantaneous bandwidth of up to 200 MHz.

Highlights
  • Wide frequency range : 220 MHz to 7.125 GHz
  • Support of instantaneous 200MHz channel bandwidth
  • Up to MIMO 4×4 in TX and RX
  • Compact size : 8.4 mm x 4.8 mm x 1 mm – in a 178-pin BGA package
  • 20 receive (Rx) paths and 4 transmit (Tx) paths
  • 10 RF synthesizers to enable concomitant observation/ scanning operations
  • Unlimited frequency list for Frequency Hopping and anti-jam scenarios
  • Multiple interfaces, including DigRF V4.0 and JESD 204C
  • Low power consumption: Sleep: 0.2 mA, Standby: 3 mA, Idle: 8 mA
  • Easy integration with any SDR CPU/FPGA
Product brief

Addressing the Needs for the Most Demanding SDR Applications


Space & Defense


Drone


Wireless Access


V2X


Infrastructure


Critical Communication
