Force Policy: Learning Hybrid Force-Position Control Policy under Interaction Frame for Contact-Rich Manipulation

Robotics: Science and Systems (RSS), 2026

Hongjie Fang^*13, Shirun Tang^*1, Mingyu Mei^*14, Haoxiang Qin³, Zihao He³, Jingjing Chen³, Ying Feng³⁵, Chenxi Wang¹, Wanxi Liu¹², Zaixing He⁴, Cewu Lu¹²³⁵, Shiquan Wang^12†

¹Noematrix ²Flexiv ³Shanghai Jiao Tong University ⁴Zhejiang University ⁵Shanghai Innovation Institute

^*Equal contribution. ^†Corresponding author.

Force Policy is a global-local vision-force policy for contact-rich manipulation. A global vision policy (RISE-2) guides free-space motion, and upon contact a high-frequency local force policy estimates the interaction frame and executes hybrid force-position control. A dual-policy asynchronous scheduler coordinates the two policies during deployment.

ForcePolicy/
├── adaptor/               # Interaction Frame (IF) recovery & labeling pipeline
│   ├── interaction_frame/ # frame identifiers (twist_wrench / wrench_only / ...), labelers
│   └── visualization/     # 2D/3D labeling visualization
├── policy/                # Policy networks
│   ├── force_policy/       # local force policy (ResNet+FiLM, GRU, gated fusion, MIP/MLP heads)
│   ├── vision_policy/      # RISE / RISE-2 (global policy)
│   └── policy_modules/     # RISE sparse(Minkowski)/dense(DINOv2) modules, diffusion, MIP
├── data_infra/            # datasets, processors, normalization, augmentation, point cloud ops
├── trainer/               # DDP trainer
├── runner/                # deployment: agents, schedulers (slow-fast / adaptive / vanilla), DTW
├── vision_feat_generator/ # offline RISE-2 feature extraction (global feature φ(I))
├── configs/               # task/agent/dataset/processor/scheduler/policy/adaptor configs
├── scripts/               # data preprocessing, calibration, labeling, visualization tools
├── utils/                 # transforms (pose/rotation/twist), visualization helpers
├── run_adaptor.py         # IF labeling entry
├── run_generator.py       # vision feature generation entry
├── run_trainer.py         # training entry
└── run_eval.py            # real-robot evaluation entry

Tested with Python 3.10, CUDA 12.x, PyTorch 2.4.1.

conda create -n forcepolicy python=3.10 -y
conda activate forcepolicy

# Core dependencies
pip install -r requirements.txt

The global policy reuses the RISE-2 backbone, so its environment must be set up the same way. Follow the official RISE-2 installation guide for PyTorch, MinkowskiEngine, PyTorch3D, and the pretrained DINO weights. Key points:

• Use CUDA 12.1 to avoid compatibility issues (set CUDA_HOME before building).
• MinkowskiEngine — do not install the official NVIDIA package. RISE-2 ships a patched fork that builds against CUDA 12.x; install it from chenxi-wang/MinkowskiEngine (cuda-12-1 branch) exactly as described in the RISE-2 guide. This sparse 3D conv backbone is used by RISE-2.
• PyTorch3D — install from source per the RISE-2 guide; used here by utils/transforms/rotation.py for rotation conversions.
• DINO weights — download the pretrained DINOv2/DINOv3 weights into a weights/ folder following the RISE-2 guide; the RISE-2 dense encoder loads them from there.

Required only for real-robot evaluation (run_eval.py), not for training:

• easyrobot — hardware abstraction for the Flexiv arm/gripper and Intel RealSense cameras.
• flexivrdk — Flexiv Rizon SDK (hybrid force-position controller interface).

The hardware platform in the paper is a Flexiv Rizon 4 arm with a GN-02 gripper, a flange-mounted 6-DoF force/torque sensor, and two Intel RealSense D415 cameras (one global, one wrist-mounted).

Demonstrations are collected with an arm-to-arm teleoperation system with force feedback (Flexiv TDK), 50 demonstrations per task. In this setup a leader and a follower arm are synchronized with force/torque feedback, so the operator feels the contact forces measured at the follower during teleoperation. During recording:

• RGB-D images are saved at 15 Hz;
• robot state (end-effector pose, end-effector velocity, force/torque) is recorded at 1000 Hz.

Provided data & checkpoints (Push and Flip). For the full Push and Flip task we provide the sample demonstrations we used, together with the trained RISE-2 and Force Policy checkpoints: Google Drive.

data/<task>/<split>/
  scene_0001/
    cam_<serial>/
      color/<timestamp_ms>.png
      depth/<timestamp_ms>.png
      intrinsic.npy            # 3x3
      extrinsic.json           # {"pose_in_link": [x,y,z,qw,qx,qy,qz]}
    lowdim/
      lowdim.h5                # raw recording
      lowdim_filled.h5         # 1000 Hz interpolated (scripts/fill_data.py)
      lowdim_labeled.h5        # IF / wrench / mask labels (run_adaptor.py)
      vision_feat_<cam>.h5     # precomputed global feature (run_generator.py)
  scene_0002/
  ...

Lowdim HDF5 fields carry a robot/arm id suffix (e.g. tcp_pose_062703, force_torque_062703).

1. Calibration. You need to calibrate the global camera(s), then convert the result into the required format with the scripts below:

   python scripts/save_intrinsic.py --serial <camera_serial> --output intrinsic.npy
   python scripts/generate_calib.py --camera global:<serial>:intrinsic.npy:extrinsic.json --main_serial <serial> --output_path calib/
   python scripts/sync_calib_to_scenes.py --calib_dir calib/ --data_root data/<task>/<split> --camera_serial <serial>

2. Interpolate low-dim signals to 1000 Hz:

   python scripts/fill_data.py \
     --data_path data/<task>/<split> \
     --fields_info "tcp_pose:lowdim.h5:tcp_pose_<id>:float64:pose_linear ..." \
     --save_name lowdim_filled.h5

   (--save_name is given without the extension; fill_data.py writes lowdim_filled.h5, which is the interpolated low-dim file consumed by the adaptor and the training datasets.)

3. Interaction Frame (IF) labeling. The labeler recovers the IF orientation, the four task modes (Free / Surface / Insertion / Rotation), the selection mask S, and the reference wrench.

   Important — use the per-task adaptor config. The adaptive (twist_wrench) method needs different thresholds for each task, so every task has its own config file. Pass it via --adaptor (resolved by name to configs/adaptor/<name>.py). Do not reuse one task's config for another.

   Paper task	--adaptor	Config file
   Push and Flip	twist_wrench_flip	configs/adaptor/twist_wrench_flip.py
   Plug in EV Charger	twist_wrench_charger	configs/adaptor/twist_wrench_charger.py
   Scrape off Sticker	twist_wrench_shovel	configs/adaptor/twist_wrench_shovel.py

   Run it once per task (example uses Push and Flip; swap --adaptor and --task_path for the others):

   python run_adaptor.py \
     --adaptor twist_wrench_flip \
     --task_path data/<task>/<split> \
     --lowdim_name lowdim_filled.h5 \
     --save_lowdim_name lowdim_labeled.h5 \
     --tcp_pose_key tcp_pose_<id> --tcp_vel_key tcp_vel_<id> --wrench_key force_torque_<id>
     --vis_name adaptor_result.png

   Choosing the power source (specify). The dominant contact power source selects the IF reconstruction formula: dissipative (friction dominates) → specify='twist' (orthogonalize wrench against twist); structural (stiffness dominates) → specify='wrench' (orthogonalize twist against wrench). It can be set in three ways:

   Option 1 — Using Gemini. Classify the power source per patch from the patch's initial frame, yielding a time-varying specify along the trajectory. This is a two-step process.

   1. Produce a per-patch specify sequence for every scene. Use the same --patch_size as the task's adaptor config (10 for flip/charger, 50 for shovel), and a task reference image showing the overall phase scope (omit --reference_image to fall back to each scene's first frame):

      export GEMINI_API_KEY=<your_key>
      python scripts/classify_power_source.py \
        --task_path data/<task>/<split> \
        --task_description "flip the box: a constrained rotation of the orange box against the vertical wall boundary to transition it from a horizontal to a vertical pose, maintaining contact with the wall to overcome interface friction" \
        --patch_size 10 \
        --reference_image path/to/task_reference.png \
        --lowdim_name lowdim_filled.h5 \
        --output power_source_specify.json

      This writes power_source_specify.json into each scene's lowdim/ directory, containing a per-patch specify list aligned 1:1 with the adaptor's patches.

   2. Run the adaptor with --specify_seq_name so it consumes the per-patch sequence (the --patch_size in step 1 must match this adaptor config):

      python run_adaptor.py \
        --adaptor twist_wrench_flip \
        --task_path data/<task>/<split> \
        --lowdim_name lowdim_filled.h5 \
        --save_lowdim_name lowdim_labeled.h5 \
        --tcp_pose_key tcp_pose_<id> --tcp_vel_key tcp_vel_<id> --wrench_key force_torque_<id> \
        --specify_seq_name power_source_specify.json

   If using Gemini (or another LLM) is inconvenient, the power source can also be set manually from expert knowledge, or detected automatically with a kinematic threshold:

   Option 2 — Specify. If you already know a task is purely dissipative or structural, hard-set specify='twist' or specify='wrench' in configs/adaptor/twist_wrench_<task>.py, then run the run_adaptor.py command above (without --specify_seq_name).

   Option 3 — Auto detect. Set specify='auto' in the task's adaptor config to switch by a kinematic threshold, then run the run_adaptor.py command above (without --specify_seq_name).

   Visualize the labels for QC (see §3.4 for how to read the plot and tune the config):

   python scripts/visualize/vis_label.py --tcp_file <lowdim_filled.h5> --labeled_file <lowdim_labeled.h5>
   python scripts/visualize/vis_label_3d.py --cam_dir <scene>/cam_<serial> --tcp_file ... --labeled_file ...

Label quality directly determines Force Policy performance, so iterate on the adaptor config until the labels look right before training. The workflow is: run the adaptor with visualization → inspect the plot → adjust thresholds → repeat. We walk through it with the Push and Flip task and configs/adaptor/twist_wrench_flip.py.

Step 1 — Run the adaptor with visualization. Add --vis_name to run_adaptor.py to render a per-scene labeling plot into each scene's lowdim/ directory:

python run_adaptor.py \
  --adaptor twist_wrench_flip \
  --task_path data/flip/train \
  --lowdim_name lowdim_filled.h5 \
  --save_lowdim_name lowdim_labeled.h5 \
  --tcp_pose_key tcp_pose_<id> --tcp_vel_key tcp_vel_<id> --wrench_key force_torque_<id> \
  --vis_name label_vis

You can also regenerate the plot for our bundled single-scene example without any data collection:

python scripts/visualize/vis_label.py \
  --tcp_file assets/example_flip_lowdim_filled.h5 \
  --labeled_file assets/example_flip_lowdim_labeled.h5

Step 2 — Read the visualization. The plot below is the expected result for a good flip label:

• Left (3D): the TCP trajectory (black) with the recovered Interaction Frame drawn along contact phases (red = x / motion axis, green = y, blue = z / contact-normal axis). Check that the frame is stable and physically sensible — e.g. z pointing into the contact/wall, x along the sliding/rotating direction — rather than flipping around randomly.
• Right (6 panels): twist (blue, m/s or rad/s) and wrench (orange, N or Nm) expressed in the Interaction Frame, per axis. The background color is the classified task mode (Free / Surface / Insertion / Rotation). Check that the shading matches what actually happens (free approach → contact/press → constrained rotation), and that the force concentrates on the expected axis (here, the normal axis) once contact starts.

Step 3 — Tune the parameters. configs/adaptor/twist_wrench_flip.py builds a DataAdaptorConfig with three parts:

• patch_size — number of consecutive 1000 Hz samples that share one IF / one task-mode decision. Smaller = finer in time but noisier; larger = smoother but blurs fast transitions (flip/charger use 10, shovel uses 50). If the mode shading flickers with many tiny segments, increase it.
• calc_twist_from_pose — if True, twist is differentiated from pose; if False, the recorded tcp_vel is used. Use True only when recorded velocity is missing/noisy.

frame_identifier_config (TwistWrenchFrameIdentifier) recovers the IF orientation per patch:

• specify — power source, 'auto' | 'twist' | 'wrench' (see §3.3). Controls which signal is orthogonalized against which when building the frame.
• weight_angular — how much angular velocity (vs. linear velocity) contributes to the motion (x) axis. Raise it for rotation-dominated tasks like flipping so the frame follows the rotation.
• weight_torque — how much moment (vs. force) contributes to the contact-normal (z) axis. Raise it when the informative contact signal is torque rather than force.
• thres_lin_vel / thres_ang_vel — in 'auto' mode, the speed thresholds that decide twist-dominant vs. wrench-dominant behavior for a patch.
• thres_parallel — when the candidate motion and force axes are nearly parallel (dot product above this), the frame falls back to a safe default to avoid a degenerate/ambiguous orientation.

frame_labeler_config (AdvancedFrameLabelerConfig) classifies each patch into Free/Surface/ Insertion/Rotation and produces the selection mask S and reference wrench:

• thres_force / thres_torque — contact detection thresholds. Force/torque below these means "no contact" → the patch is labeled Free. Lower them if contact onset is detected too late; raise them if noise creates spurious contact.
• thres_lin_vel / thres_ang_vel — velocity thresholds separating motion vs. quasi-static and rotation-dominated modes.
• thres_is_parallel — alignment threshold used when deciding axis relationships for the mode/mask.

Temporal-smoothing knobs on DataAdaptorConfig (enable_smoothing, min_run_length, conf_threshold, sim_threshold, sim_window_size) clean up short, low-confidence mode runs; if real short phases get absorbed, raise sim_threshold or lower min_run_length.

Step 4 — Iterate. Re-run Step 1 after each change and re-inspect the plot. Typical fixes: contact detected too late/early → adjust thres_force; too many spurious mode flips → increase patch_size or min_run_length; the frame flips near parallel configurations → tune thres_parallel / thres_is_parallel; rotation/torque under-represented in the frame → raise weight_angular / weight_torque. Only once the labels look clean and consistent across scenes should you proceed to training.

Force Policy is trained in two stages. Stage 1 trains and freezes the global RISE-2 policy and extracts its 512-D action feature; Stage 2 trains the local force policy conditioned on that feature. Replace <task> triplets using the table below.

CUDA_VISIBLE_DEVICES=0,1,2,3 torchrun --nproc_per_node 4 run_trainer.py \
  --trainer RISE2 \
  --dataset <dataset_vis> \
  --processor <rise2_processor> \
  --policy vision_policy.RISE2_robot_only \
  --wrapper vision_policy.RISE2_robot_only \
  --ckpt_dir logs/log_<task>_rise2/

CUDA_VISIBLE_DEVICES=0 python run_generator.py \
  --dataset <dataset_vis> \
  --processor <rise2_processor> \
  --policy vision_policy.RISE2_robot_only \
  --wrapper vision_policy.RISE2_robot_only \
  --ckpt_path logs/log_<task>_rise2/policy_last.ckpt

This writes vision_feat_<cam>.h5 into each scene's lowdim/ directory.

CUDA_VISIBLE_DEVICES=0,1 torchrun --nproc_per_node 2 run_trainer.py \
  --trainer force_policy \
  --dataset <dataset_wrist> \
  --processor <force_processor> \
  --policy force_policy.vision_feat_wrist_vision_cond_comb_lowdim_cond_gated_with_global_sep_action_mip_other_1_step \
  --wrapper force_policy.force_policy \
  --ckpt_dir logs/log_<task>_force_policy/

The main configuration ..._sep_action_mip_other_1_step uses separate decoder heads: a MIP head for the 50 Hz action chunk and MLP heads for the interaction frame, reference wrench, and selection mask. Loss weights: action=1.0, frame=1.0, force=1.0, mask=0.1.

Deployment uses the dual-policy asynchronous slow-fast scheduler: RISE-2 runs as the slow global policy and Force Policy runs as the fast local policy at 50 Hz, routed by the predicted selection mask S, with DTW-based chunk alignment and acceleration-continuous trajectory planning dispatched to the Flexiv hybrid force-position controller.

Hardware configuration required. Camera serials, robot serials, and extrinsics are hard-coded in configs/agent/<profile>/agent.py and configs/agent_class/<task>.py. Update these to match your own setup. Deployment requires easyrobot and flexivrdk.

The provided profiles are tied to our hardware (serials, extrinsics, joint poses). For your own robot you must create two configs. Both are resolved by name, so copy an existing one as a template and rename.

configs/agent/<your_profile>/ — describes the physical platform and what each policy observes. It is a small package with three files:

• agent.py — instantiate your hardware and build agent_config = RealAgentConfig(...):
  • construct your FlexivArm(...), RealSenseRGBDCamera(...), and grippers with your own robot/camera serials and the matching shared-memory managers;
  • fill platform_config (camera/robot names), robots, cameras, intrinsics, extrinsics (4×4 camera-to-base matrix, hand-eye calibrated), robot_poses, and force_control_robot_names.
• obs_key.py — define obs_key_configs, one AgentObsKeysConfig per observation key:
  • vision_RISE2 (slow/global policy): which color/depth/intrinsic/extrinsic cameras it reads;
  • force_policy (fast/local policy): the wrist color_keys plus the lowdim_provider_keys it needs (e.g. tcp_pose, force_torque, aux_tcp_pose).
  • These keys are passed at runtime via --agent_obs_keys and --fast_agent_obs_keys.
• __init__.py — leave empty.

configs/agent_class/<your_task>.py — defines a task-specific Agent(RealAgent) subclass, mainly the ready() routine that brings the robot to a safe start state. Adapt:

• the ready joint pose (tar_pose_q_deg) to your workspace;
• the F/T sensor zeroing (zero_ft_sensor), control mode (e.g. NRT_SUPER_PRIMITIVE), SetCartesianImpedance, SetForceControlAxis, and SetMaxContactWrench to your task's contact regime.

Then run run_eval.py with --agent <your_profile> --agent_class <your_task>.

Example (Plug in EV Charger):

python run_eval.py \
  --processor charger.RISE2_top \
  --policy vision_policy.RISE2_robot_only \
  --wrapper vision_policy.RISE2_robot_only \
  --agent single_charger_top --agent_obs_keys vision_RISE2 --agent_class charger \
  --scheduler charger.slow_fast \
  --ckpt_path logs/log_charger_v2_rise2/policy_last.ckpt \
  --fast_processor charger.force_policy.wrist \
  --fast_policy force_policy.vision_feat_wrist_vision_cond_comb_lowdim_cond_gated_with_global_sep_action_mip_other_1_step \
  --fast_wrapper force_policy.force_policy \
  --fast_agent_obs_keys force_policy \
  --fast_ckpt_path logs/log_charger_v2_force_policy/policy_last.ckpt \
  --visualize --vis_robot right

• Our vision policy is built on RISE-2, with the original CC BY-NC-SA 4.0 license. The sparse 3D encoder uses a patched MinkowskiEngine, and the dense encoder uses DINOv2/DINOv3 features.
• Our diffusion module is adapted from Diffusion Policy (MIT License).
• Our transformer module is adapted from ACT, which builds on DETR (Apache-2.0 License).
• Our remote-evaluation serialization is adapted from msgpack-numpy.
• Data collection uses the Flexiv TDK force-feedback teleoperation system; real-robot deployment uses easyrobot and the Flexiv RDK.

If you find this work useful, please consider citing:

@inproceedings{fang2026forcepolicy,
  title     = {Force Policy: Learning Hybrid Force-Position Control Policy under Interaction Frame for Contact-Rich Manipulation},
  author    = {Fang, Hongjie and Tang, Shirun and Mei, Mingyu and Qin, Haoxiang and He, Zihao and Chen, Jingjing and Feng, Ying and Wang, Chenxi and Liu, Wanxi and He, Zaixing and Lu, Cewu and Wang, Shiquan},
  booktitle = {Proceedings of Robotics: Science and Systems (RSS)},
  year      = {2026}
}

All data, labels, code and models belong to the Noematrix Ltd. and MVIG@SJTU, and are licensed under a Creative Commons Attribution 4.0 Non Commercial License (CC BY-NC-SA). They are freely available for non-commercial use only, and may be redistributed under these conditions. Commercial use is prohibited.
