Oracle Solaris Cloud Management and Deployment with OpenStack
- 2.
- 3.
- 4. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Program Agenda OpenStack & Cloud: State of the Enterprise OpenStackOverview Designing your Cloud Architecture: Best Practices Q&A 1 2 3 4 4
- 5. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Program Agenda OpenStack & Cloud: State of the Enterprise OpenStackOverview Designing your Cloud Architecture: Best Practices Q&A 1 2 3 4 5
- 6. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Cloud Computing: State of the Enterprise What’s Driving Enterprises to Cloud Systems? • Cloud Benefits IT Consumers –Agility through self-service automation – On-demand provides OpEx vs. CapEx options • Cloud Benefits IT Providers – Better capacity planning and asset utilization – Centralized monitoring and reporting – Manage IT as a collection of provided services • Not surprising: Many Enterprises have, or are looking to either deploy new clouds, or shift to cloud based management for existing infrastructure 6
- 7.
- 8.
- 9. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Program Agenda OpenStack & Cloud: State of the Enterprise OpenStackOverview Designing your Cloud Architecture: Best Practices Q&A 1 2 3 4 9
- 10.
- 11.
- 12. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | OpenStack Services ComponentDescription Component Description Nova Compute virtualization Glance Image management and deployment Cinder Block storage Swift Object storage Neutron Software defined networking Heat Application and VM orchestration Keystone Authentication between cloud services Murano Application catalog Horizon Web based dashboard Trove Database as a Service Overview of Core Components 12
- 13.
- 14. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 11.2 SRU 1 Image Packaging System • Seamless integration with IPS –Full dependency management – Fail proof updates with rollback • Integrated with Oracle Solaris Zones and Unified Archives for seamless lifecycle management • Foundation for cloud update strategy – Configuration and database schemas updated through SMF update services with full rollback Easy and fast cloud update 11.3Clone 14
- 15. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Service Management Facility • OpenStackservices run with minimum privileges necessary, and don’t run as root – Create users for different OpenStack services – Leverage RBAC to enable privileged actions • Automatic service restart from failure – Integrated with Oracle Solaris fault management – Full dependency checking for precise and efficient cloud start up Secure and Highly available and reliable cloud services xx SMF Services 15
- 16. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | OpenStack Cinder/Swift Data Management –ZFS • ZFS is foundation for Cinder and Swift – iSCSI or FC LUN provisioning – Leverage integrated data services including snapshots, compression and encryption – These data services are completely transparent to the guests • Integrated OpenStack support for ZFS SA Production ready data management, no compromises Virtual Environments Cinder Volume ISCSI LUNISCSI LUNISCSI LUN 16
- 17. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Oracle Solaris Immutable Guest # Immutable Guest Firewall • The undercloud locked down – OpenStack nova-compute nodes run with dynamic-zone policy – Allowing only Zones to be installed and run but otherwise completely locked • The guest instances – Through OpenStack flavors as part of nova the tenant user can choose to use any of the other policy – Use none for development and strict for production for exmaple 17 Using Immutable Zones in OpenStack
- 18. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Bare Metal Provisioning with Ironic OpenStack Kilo in Oracle Solaris 11.3 18 •Manage and deploy bare metal in addition to virtual machines – Oracle Solaris Zones, Oracle Solaris Kernel Zones, Oracle Solaris Bare Metal – Use same Unified Archive for physical and virtual deployments • Integrated with Automated Installer deployment framework Compute Oracle Solaris Zones Bare Metal Environments Oracle Solaris Kernel Zones
- 19. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | OpenStack Kilo in Oracle Solaris 11.3 •Engineered for security and compliance – Minimal privileges for cloud services – Lock down infrastructure with immutability • Assured reliability and scale – Automatic service restart and node dependencies – Guaranteed data integrity • Seamless upgrade, instant roll-back • SPARC, x86, Virtualized and Bare Metal Environments OS. Virtualization. SDN. OpenStack. Complete. 19
- 20. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Program Agenda OpenStack & Cloud: State of the Enterprise OpenStackOverview Designing your Cloud Architecture: Best Practices Q&A 1 2 3 4 20
- 21. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 21 OpenStackPhysical Layout Network Node Storage Node Storage Network Cloud Network Compute Node Compute Node Compute Node Compute Node Compute Node Public Network 7/7/16
- 22. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 22 Flat Networking Model OpenStackPhysical Layout Storage Node Storage Network Cloud Network Compute Node Compute Node Compute Node Compute Node Compute Node Public Network 7/7/16
- 23. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 23 General Cloud Architecture with OpenStack Controller OpenStackPhysical Layout Network Node Storage Node Storage Network Cloud Network OpenStack Network Compute Node Compute Node Compute Node Compute Node OpenStack Controller Compute Node Public Network 7/7/16
- 24. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 24 “Cloud In a Rack“ Case Study from OOW 2015 OpenStackPhysical Layout Network Node Storage Node Storage Network Cloud Network OpenStack Network Compute Node Compute Node Compute Node Compute Node OpenStack Controller Compute Node Public Network 7/7/16 CI Rack
- 25. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Design Considerations • Build a cloud with Oracle Solaris OpenStack –Fully supported, Enterprise ready Software Stack – Optimized for Oracle Database Workload • Lock-down the Cloud – Outsite Network Access only by OpenStack Instances – No direct Access to Infrastructure Components and Control Logic • Virtualize the Workload. Virtualize the Control Logic – Power the Infrastructure and the Workloads with Solaris Zones 25 Make it Easy to Maintain and Secure
- 26. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Oracle Solaris Solaris Kernel Zones Advantages • Virtualization Mobility •No Virtualization Overhead • Unified Setup for Development/Test/Production of the Platform – Global Zone, NonGlobal Zone, Kernel Zone - it's always a Zone • Flexible Scalability for the Control Plane – Scale vertical • Add CPU and Memory to a Kernel Zone – Scale horizontal • Add another Node: Add another Kernel Zone 26 Virtualize the Workload and Virtualize the Control Logic Oracle Solaris iSCSI Solaris 11.2 KZone Solaris 11.3 KZone Solaris 11.3 KZone
- 27. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Simplified Cloud Lifecycle Management • Create a replicable Setup with AI, IPS, BE's and FBS –Use Automated Installer (AI) to Install Zones and Nodes – Install and Update OpenStack Software as IPS-Packages • OpenStack Configuraton through First Boot Services (FBS) or Puppet • Setup and Configure the Cloud in Minutes not Days • Enable Cloud LifeCycyle Management with Boot Environments (BE) 27
- 28. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Database-as-a-Service with Trove Futures - Work in Progress 28 •Provision and manage database instances in the cloud – Currently supports MySQL and other open source databases – Oracle Database in roadmap • Integrated into OpenStack Horizon dashboard Clustered Database Single Instance Databases
- 29.
- 30. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | Getting Started • Oracle OpenStackfor Oracle Solaris, and Oracle Linux – http://www.oracle.com/openstack • On the OpenStack Marketplace – http://www.openstack.org/marketplace • Source Code for Solaris OpenStack Drivers – https://java.net/projects/solaris- userland/sources/gate/show/components/openstack OpenStack on Oracle Solaris resources
- 31. Copyright © 2015, Oracle and/or its affiliates. All rights reserved. | 31 Questions? •oracle.com/solaris • @ORCL_Solaris • facebook.com/oraclesolaris • Oracle Solaris Insider • blogs.oracle.com/solaris • youtube.com/oraclesolaris Learn More; Stay Connected
