High-Performance Composite Filaments
Fiberon™ PPS-GF20
Industrial-grade strength, high heat resistance, and V0 FR for the best insulation
HDT(°C)
0.45MPa236.3 °C
0.45MPa236.3 °C
Young's
Modulus
Dry4552.0 MPa
Modulus
Dry4552.0 MPa
Young's
Modulus
Wet
Modulus
Wet
Spool info:
1.75mm
500g, 3kg
About PPS-GF20
TDSSDS
Fiberon™ PPS-GF20 is a 20% glass fiber-reinforced polyphenylene sulfide filament engineered to deliver enhanced mechanical strength and dimensional stability. This advanced material maintains electrical insulation properties while achieving UL94 V0 Flame Retardance (1.5mm). Its inherent chemical resistance ensures reliable performance in demanding automotive, electronics, and industrial applications.
Application Category
Automotive
Electronics
Industrial parts
HDT (0.45MPa)
HDT(°C)236.3 °C
Young's modulus
Dry4552.0 MPa
Wet
Tensile strength
(x-y)
64.1 MPa
(z)
22.9 MPa
Charpy Impact strength
notched
notched
(x-y)
7.3 kJ/m2
Bending modulus
(x-y)
4110.7 MPa
(*) all data are from printed specimen
V0 Flame Retardance
Good Insulation Properties
Printer compatibility
Printing temperature: 310–350 °C
Bed temperature: 90 °C
(*) No heated chamber or enclosure needed
Bed temperature: 90 °C
(*) No heated chamber or enclosure needed
Nozzle compatibility
Brass nozzles wear quickly when printing Fiberon™ PPS-GF20. Use a wear-resistant nozzle such as hardened steel or ruby.
