JLCPCB

@JLCPCB

JLCPCB-Easy, Affordable and Reliable PCB Manufacturing! $2 for 1-8 layer PCB prototyping; PCB Assembly from $0 ; bit.ly/43EDEvF for coupon.

Germany

Pinned
JLCPCB
@JLCPCB
Jul 10
🚀 EasyEDA Spark 2026 is LIVE! 🏆 Compete for a share of the $85,000 prize pool 📦 Material & shipping support 🎁 $100 JLCPCB coupon for every completed project 🏭 JLCPCB Factory Tour 🌍 EasyEDA Spark Conference 2027 🔗 oshwlab.com/activities/eas… #EasyEDASpark #JLCPCB #OSHWLab
JLCPCB
@JLCPCB
17h
Have you ever tried hand-soldering ultra-small capacitors? One wrong move and the soldering iron burns your finger. 😭 Want to know how to choose the right SMD capacitor size for your project? 👉 Check out the article: jlcpcb.com/blog/smd-capac… #JLCPCB #SMD
JLCPCB
@JLCPCB
20h
Gerbers finalized, PCBs freshly delivered from JLCPCB. Plug in power, and everything goes sideways. Deploying emergency tiny repair crew to fix all my SI / PI / EMC mistakes directly on the board 🛠️ 🖥️Simulation: “All parameters perfect.” 🔌Real hardware: “Hold my beer.”
JLCPCB
@JLCPCB
Aug 29
Why do some BGA pads have tiny holes? 🤔 They’re not a design mistake. Via-in-Pad places a via directly inside the pad to save routing space. But if it’s not properly filled, solder can wick into the hole during reflow, causing soldering issues. #PCBDesign #BGA #JLCPCB
JLCPCB
@JLCPCB
Aug 29
👀 What do you think this FPC is designed for? Those serpentine traces aren’t just for looks. A. Wearables B. Motion / strain sensing C. Robotics D. Something else 👇 Drop your guess! #JLCPCB #FPC #PCBDesign
