Development with PaaS
An introduction using Heroku and Spring
Roberto Casadei
Concurrent and Distributed Programming course
Department of Computer Science and Engineering (DISI)
Alma Mater Studiorum – Università of Bologna
June 16, 2018
PCD1718 PaaS-Intro GAE Heroku Spring Cloud Example: Heroku+Spring 1/38

Outline
1 Introduction: PaaS
2 Google AppEngine: a Quick Outlook
3 Heroku
4 Spring Cloud
5 Example: Heroku+Spring

Introduction: PaaS
Platform-as-a-Service (PaaS)
NIST deﬁnition: “The capability provided to the consumer is to deploy onto the cloud
infrastructure consumer-created or acquired applications created using
programming languages and tools supported by the provider. The consumer
does not manage or control the underlying cloud infrastructure including
network, servers, operating systems, or storage, but has control over the deployed
applications and possibly application hosting environment conﬁgurations.”

PaaS is fuzzy
Beware: there is not only one PaaS model
https://blog.mccrory.me/2011/01/23/current-paas-patterns-types-of-paas/
1) Upload your environment as a VM/container (cf., IaaS)
2) Upload your compiled/packaged application (e.g., WAR)
3) Upload your code—compilation happens in the PaaS itself (cf., Heroku)
4) Upload platform-speciﬁc code (cf., Salesforce)
“Comparing PaaS Offerings in Light of SaaS Development”[4]
1) Unfocused PaaS platforms that mimic and match the APIs of popular
enterprise application servers and middleware platforms (e.g., Heroku, Cloud
Foundry, Azure, OpenShift)
2) Focused PaaS platforms—aim to optimally support speciﬁc types of cloud
applications, for better scalability (e.g., GAE)
3) Metadata-driven PaaS platforms (e.g., Salesforce)
https://www.youtube.com/watch?v=V_lM59cvGoI
1) Bring Your Own Code pattern
2) Bring Your Own Container pattern

Outline
3 Heroku
4 Spring Cloud

GAE: Flexible vs. Standard Environment

GAE: Flexible vs. Standard Environment
Standard Environment
Application instances run in a sandbox, using the runtime environment of a
supported language (Python 2.7, Java 7/8, PHP 5.5, Go 1.6/1.8/1.9)
Building an application is more constrained and involved, but your apps will have
faster scale up times, better reacting to sudden and extreme spikes of trafﬁc.
Flexible Environment
Application instances run within Docker containers on GAE VMs
Use a predeﬁned runtime (Python, Java, Node.js, Go, Ruby, PHP, .NET) or build
your custom runtime to support any PL/framework
Your apps can depend on other SW, including OS packages through apt-get
No sandbox limitations: you can create threads, processes, sockets.
No GAE APIs: apps are written like standard web apps that can run anywhere
Google Cloud client libraries to call Google Cloud Services
These client libraries work everywhere ⇒ your app is more portable
https://cloud.google.com/appengine/docs/the-appengine-environments

Google Cloud SDK
Google Cloud SDK is a set of tools for accessing Google Cloud services via
command-line
1) Install it: you’ll get, among other things, a tool gcloud
2) Setup: $ gcloud init
Authorizes Cloud SDK tools to use your user account credentials to access Google
Cloud Platform
Sets up a Cloud SDK conﬁguration (i.e., a set of properties)
$ gcloud config list
3) View/Install SDK components: $ gcloud components list
app-engine-java: gcloud App Java Extensions
gcd-emulator: emulator for Google Cloud Datastore

GAE: example (i)
Java web apps for GAE use the standard Java Servlet interface1
An app is deployed as a Web Application Archive (WAR)
The Java GAE SDK is the bridge to GAE and supports simulating GAE locally
/src/main/java/it/unibo/MyServlet.java
public class MyServlet extends HttpServlet {
public void doGet(HttpServletRequest req, HttpServletResponse resp)
throws IOException {
resp.setContentType("text/html");
resp.getWriter().println("Hello GAE");
} }
/src/main/webapp/WEB-INF/web.xml
<web-app ....>
<servlet>
<servlet-name>myservlet</servlet-name>
<servlet-class>clock.MyServlet</servlet-class>
</servlet>
<servlet-mapping>
<servlet-name>myservlet</servlet-name> <url-pattern>/</url-pattern>
</servlet-mapping>
</web-app>
1https://guides.gradle.org/building-java-web-applications/

GAE: example (ii)
/build.gradle
apply plugin: 'java'
apply plugin: 'war'
dependencies {
compile 'com.google.appengine:appengine-api-1.0-sdk:+'
providedCompile 'javax.servlet:javax.servlet-api:3.1.0'
} // providedCompile to prevent inclusion in the packaged .war
// those dependencies will be provided by the container
Gradle plugin for GAE is also available2
Build: $ gradle build
Running the GAE app locally: $ dev_appserver <path/to/war>
2https://cloud.google.com/appengine/docs/standard/java/tools/gradle

GAE: example (iii)
Registring/uploading the app to the cloud
Access the Google Cloud Console:
https://console.developers.google.com
Create a new project with a name, e.g., myapp
Provide a deployment descriptor:
/src/main/webapp/WEB-INF/appengine-web.xml
<appengine-web-app xmlns="http://appengine.google.com/ns/1.0">
<application>myapp</application>
<version>1</version>
<threadsafe>true</threadsafe>
</appengine-web-app>
Rebuild so that the WAR includes the deployment descriptor
Deploy: $ appcfg update <path/to/war>
You’re done at http://<projectID>.appspot.com/
The Console includes a Dashboard for viewing usage statistics
To use more resources, enable billing.

GAE: example (iv)
Example of Cloud service (Users API): handling users via Google Accounts
import com.google.appengine.api.users.*;
//...
UserService userService = UserServiceFactory.getUserService();
User user = userService.getCurrentUser();
if(user == null){
String loginUrl = userService.createLoginURL("/login.jsp");
// ...
} else {
String logoutUrl = userService.createLogoutURL("/logout.jsp");
// ...
}
When the app is running in the development server, the login link goes to the dev
server’s simulated version of the Google Accounts sign-in screen.

Outline
3 Heroku
4 Spring Cloud

Heroku: intro
Heroku
Heroku is a PaaS: it lets you deploy, run and manage applications
Heroku services are hosted on Amazon’s EC2
Pro: very easy to deploy and configure applications
Pro: does not force you to code against vendor-specific APIs
Con: can get expensive fast
Con: not as comprehensive as e.g. Google Cloud
Some history
Heroku was founded in 2007, initially targeting Ruby
Heroku is one of the first cloud platforms (PaaS)
In 2010, it has been acquired by Salesforce.com
In 2011, support for Node.js and Clojure was added
Now, it supports Java, Node.js, Scala, Clojure, Python, PHP, and Go

Heroku: basic concepts I
Application = source code + dependencies + Procfile
Application source code and dependencies organised as per build definition
When using a well-known framework, Heroku can figure out how to run apps
Cf., main field in package.json for Node apps
To explicitly tell Heroku what to run, you can define a Procfile
web: java -jar lib/foobar.jar $PORT
queue: java -jar lib/queue-processor.jar
Format is <processType>: <commandToRun>
Only web processes can receive web traffic
Deployment
Heroku supports multiple mechanisms for deployment
Git: by pushing to your Heroku app remote
Github integration
REST API

Heroku: basic concepts II
Building apps
When Heroku receives your app sources, it starts the building process
A slug is a bundle of your source, fetched dependencies, the language runtime,
the Procfile and compiled/generated output of the build system.
A buildpack is responsible of transforming the deployed code into a slug.
There is a set of officially supported buildpacks; these are open-source
There is also a huge num of 3rd-party buildpacks
Running apps on dynos
Dyno: a lightweight, isolated, secure, virtualized Unix container that provide the
environment required to run an app.
Apps are executed by running the commands specified in the Procfile on a dyno
that has been preloaded with a slug.
Dyno formation: the total number of currently-exeucting dynos
Each dyno gets its own ephemeral filesystem

Heroku: basic concepts III
Release = slug + configuration + addons
Configuration variables contain customizable config data that can be changed
independently of your source code and exposed to a running app via
environment variables
Add-ons are resources attached to an app
Addons provide backing services (e.g., DBs, MOMs, Logging, E-mail..)
The interface to apps is often provided through configuration variables
A new release is generated any time you change sources, config vars, or add-ons

How Heroku works: summary

Heroku: free tier
Monthly pool of free dyno hours (450 hours/month) across all apps
Up to 5 free apps (unveriﬁed account) or 100 (veriﬁed account)
Max per free app: 1 web dyno, 1 worker dyno
Free apps sleep automatically after 30 mins of inactivity
Many add-ons (e.g., Heroku Postgres and Heroku Redis) do offer free plans

Heroku Command-Line Interface (CLI)
Install: e.g., via package manager — brew install heroku (macOs)
Heroku CLI: main commands
Getting help: $ heroku help addons
Login: $ heroku auth:login
Create apps: $ heroku apps:create <appname>
Deploy apps: $ git push heroku master
Scale apps: $ heroku ps:scale web=1
Provision add-ons: $ heroku addons:create heroku-redis:hobby-dev
Set conﬁg vars: $ heroku config:set SOME_VAR=xxx
List dynos: $ heroku ps
See logs: $ heroku logs
Run a one-off process inside a dyno: $ heroku run <cmd>
Run Heroku locally: $ heroku local
Service-speciﬁc commands
$ heroku redis
$ heroku pg

Heroku CLI: deployment commands

12-factor apps
https://12factor.net
By Heroku co-founder Adam Wiggins
A methodology for building SaaS apps
1) Codebase: one codebase tracked in revision control, many deploys
2) Dependencies: explicitly declare and isolate dependencies
3) Conﬁg: store conﬁg in the environment
4) Backing services: treat backing services as attached resources
5) Build, release, run: strictly separate build and run stages
6) Processes: execute the app as one or more stateless processes
7) Port binding: export services via port binding
8) Concurrency: scale out via the process model
9) Disposability: maximize robustness with fast startup and graceful shutdown
10) Dev/Prod parity: keep development, staging, and production as similar as
possible
11) Logs: treat logs as event streams
12) Admin Processes: run admin/management tasks as one-off processes

So, how do we develop microservice apps on Heroku?
Each µservice has a Git repo
You create a Heroku app for each µservice (repo)
Each Heroku app (i.e., µservice) has a public URI
For other services (e.g., Data, MOM, Logging), use add-ons
Add-ons will inject conﬁg vars to your apps to communicate the endpoints

Outline
3 Heroku
4 Spring Cloud

Spring Cloud
Spring Cloud makes it easy to operationalize and deploy µservices to a private or
public cloud
Spring Cloud services
Spring Cloud Conﬁg: supports management of app conﬁg data through a
centralised service
Service Discovery: handles lookup and de/registration of service instances
E.g., with Eureka as service discovery engine
Hystrix integration: for resiliency patterns (circuit breaker, bulkhead..)
Ribbon integration: for service discovery and client-side load-balancing

Spring Cloud Config I
Spring Cloud Config: general config management solution for many backends
It helps you build a configuration server as a Spring Boot service
How-to
Dependency: org.springframework.cloud:spring-cloud-config-server
Annotate the Spring Boot app class with @EnableConfigServer
Configure the server: src/main/resources/bootstrap.yml
server.port: ${PORT}
spring.profiles.active: git # use git as backend
spring.cloud.config.server.git:
uri: ${CONFIG_REPO_URI}
label: master
searchPaths: /some/path/
Within <REPO>/some/path/ there are files <appname>-<env>.yml

Spring Cloud Config II
Apps will define in their bootstrap.yml:
spring.application.name: helloservice # appname
spring.profiles.active: default # profile maps to env
spring.cloud.config.uri: ${CONFIG_SERVER_URI}
and then bind config data to properties of beans
Component
public class MyConfig {
Value("${some.config.property}") private String prop;
public int getProp(){ return prop; }
//...
}
RestController
public class MyController {
Autowired MyConfig config;
//...
}

Google Cloud service discovery I
Service discovery in Spring Cloud
Services register with the Eureka service registry by providing IP, port, and
service ID
Services use Ribbon for client-side load balancing
Ribbon will contact Eureka to retrieve service info and then cache it locally.
Periodically, Ribbon will ping Eureka to refresh the local cache.
Eureka service registry
Dependency: spring-cloud-starter-eureka-server
Conﬁguration: application.yml
server.port: ${PORT}
eureka.client.registerWithEureka: false
eureka.client.fetchRegistry: false # dont't cache info
Finally, annotate the Spring Boot app with @EnableEurekaServer
Service registry URI: http://HOST:8761/eureka

Google Cloud service discovery II
Registering services with Eureka
Dependency: spring-cloud-starter-eureka
Conﬁguration: application.yml
spring.application.name: abc # logical name to register
eureka.instance.preferIpAddress: true # no server name
eureka.client:
registerWithEureka: true
fetchRegistry: true # pull down a local copy of registry
serviceUrl.defaultZone: ${SERVICE_REGISTRY_URI}

Google Cloud service discovery III
Service discovery – Approach 1: Netﬂix Feign client
Dependency: spring-cloud-starter-feign
Annotate the Spring Boot app with @EnableFeignClients
Deﬁne a service proxy bean by simply annotating an interface:
FeignClient("service-ID") public interface MyProxy {
RequestMapping(method = RequestMethod.GET,
value = "/path/{arg}", consumes="text/plain")
String getSomething( PathVariable("arg") String arg);
}
Note: also provides load balancing

Google Cloud service discovery IV
Service discovery – Approach 2: Ribbon-aware Spring RestTemplate
Create a RestTemplate bean annotated with @LoadBalanced:
SpringBootApplication public class MyApp {
LoadBalanced Bean public RestTemplate getRestTemplate(){
return new RestTemplate();
}
//...
}
Wire the RestTemplate bean in your components
Component
public class AnotherProxy {
Autowired RestTemplate rest;
public String getSomething(String arg){
return rest.exchange("http://SERVICE_ID/path/"+arg,
HttpMethod.GET, null, String.class).getBody();
} // note: SERVICE_ID is used (and not host:port!!!)
}
Note: also provides load balancing

Client Resiliency Patterns with Hystrix I
Client resiliency patterns
These pattenrs focus on protecting a client from crashing when the remote resource
is throwing errors or performing poorly.
Client-side load balancing: the load balancer can remove unstable instances
Provided by Netﬂix Ribbon libs out of the box with no extra conﬁg.
Circuit breakers: ensure a client doesn’t repeatedly call a failing service
Fallbacks: when a call does fail, it looks if there’s an alternative to run
Bulkheads: segregates different service calls to ensure a poor-behaving service
does not use all resources on the client.
Using Hystrix
Dependency: spring-cloud-starter-netflix-hystrix
Activate Hystrix by annotating the Spring app with @EnableCircuitBreaker
Annotate service component methods with @HystrixCommand to automatically
generate a proxy wrapping method calls over a thread pool.

Client Resiliency Patterns with Hystrix II
Implementing client resiliency patterns
Circuit Breaker
Component public class MyProxy {
Autowired RestTemplate rest;
HystrixCommand(commandProperties = {
HystrixProperty(name="execution.isolation.thread.
timeoutInMilliseconds",
value="5000")
}) public String getSomething(String arg){ /* as before */ };
}
Fallback pattern
HystrixCommand(fallbackMethod="fallbackGet", ...)
public String getSomething(String arg){ /* as before */ };
public String fallbackGet(String arg){ /* fallback logic */ };
Bulkhead pattern
HystrixCommand(threadPoolKey="myThreadPool", ...)
public String getSomething(String arg){ /* as before */ };

Outline
3 Heroku
4 Spring Cloud

Application structure
Repositories = heroku apps = µservices
Repos: http://bitbucket.org/unibo_disi/<appname>
Public URLs: http://<appname>.herokuapp.com/
pcd1718-paas-service-registry: Spring/Eureka service registry
pcd1718-paas-service-config: Spring Config server
The repo of the service is also the configuration data store
pcd1718-paas-helloservice: µservice with simple API
It is meant to be scaled
It uses a backing Redis data store
pcd1718-paas-serviceconsumer: µservice that depends on helloservice
Uses Spring/Ribbon/Hystrix for load balancing and client resiliency patterns
Other services
Redis: NoSQL Key/Value store
Heroku Redis addon on Cloud / local Redis server for dev

From Spring to Heroku apps
Tuning Spring µservices for Heroku
Create an app: $ heroku apps:create <appname>
Define a Procfile: since gradle bootJar packages the µservice into a JAR
within build/libs, the Procfile for <APPNAME> will be something as:
web: java -jar build/libs/<APPNAME>-<VERS>.jar
Adjust configuration to use environment variables
server.port: ${PORT} # PORT is set by Heroku!!!
spring.cloud.config.uri: ${CONFIG_SERVICE_URI}
Heroku Local development
Command e.g. heroku local web=2 starts the app locally (2 instances)
Define environment vars in .env
CONFIG_SERVICE_URI=http://127.0.0.1:8888
SERVICE_REGISTRY_URI=http://127.0.0.1:8761/eureka
REDIS_URL=redis://127.0.0.1:6379

Exercise: inspect the application
Steps
Take your time to understand all the pieces involved:
1) Clone the repositories, open a terminal tab on each
2) Try to start the system using heroku locala
You need to run redis-server to start Redis locally
You may run heroku local in background; then, keep track of the PIDs to kill by
looking at the logs.
Use -e to provide a custom xxx.env file
Use -p to specify the deployment port
3) Study the source code
4) Try to deploy the app on Heroku
You need to properly set the config vars to provide the correct URLs for each
deployed app
Attach Redis Heroku add-on to helloservice app; it will result in the injection of a
config var REDIS_URL
You won’t be able to scale it in the free tier, though
ahttps://devcenter.heroku.com/articles/heroku-local

References I
J. Carnell. Spring Microservices in Action. Manning Publications Company, 2017. ISBN:
9781617293986. URL: https://books.google.it/books?id=xDH9MAAACAAJ.
Heroku DevCenter. https://devcenter.heroku.com/. [Online; accessed 2018-06].
Spring Docs. https://spring.io/docs. [Online; accessed 2018-06].
Stefan Walraven, Eddy Truyen, and Wouter Joosen. “Comparing PaaS offerings in light of SaaS
development”. In: Computing 96.8 (2014), pp. 669–724.
PCD1718 Appendix References 38/38

Introduction to cloud-native application development: with Heroku and Spring Boot/Cloud

More Related Content

What's hot

Similar to Introduction to cloud-native application development: with Heroku and Spring Boot/Cloud

More from Roberto Casadei

Recently uploaded

Introduction to cloud-native application development: with Heroku and Spring Boot/Cloud
